Smokehouse is one of the absolutely necessary equipment in the process of making meat products.With various applications of cooking, Gradient-cooking,drying,Backing, hot smoking, Moist smoking, Exhausting and cleaning etc. Mount with smoking generators with uniform and perfect coloring.Temperature of smoke is monitored.
The advance international leading control system of PLC&HMI 10 color big screen shows you a user-friendly interface. Status of pipelines and various components are displayed graphically and intuitively.the preset value, actual value and monitoring value can be showed at the same time.Parameters can be stored and read easily and can be adjusted at any time of processing.Adopt unique airflow techniques to guarantee uniformity of airflow throughout the box.Double row can be customized
Technical Parameters
|
Model |
One trolley |
Two trolley |
Three trolley |
Four trolley |
|
Capacity (kg/time) |
250 |
500 |
750 |
1000 |
|
Power (kW) |
5.7 |
9.7 |
14.05 |
18.05 |
|
Electric Power(KW) |
30 |
60 |
90 |
120 |
|
Steam consumption (kg/h) |
80 |
120 |
160 |
|
|
External Dim. (mm) |
1100x1456x3060 |
2200x1456x3060 |
3300x1456x3060 |
4400x1456x3060 |
