This Machine is made of high quality stainless steel,reasonable in structure, easy to clean.Special surface treatment, highlywear-proof.
Advanced controlling system:Equipped with man-machine interface,servomotor as drive,simple operation.
Efficiency driving mode: The machine adopts successive driving mechanism, avoids that the parts worn too much .At the same time, the machine adopts intermittent driving mechanism, Convenient lubricating system, Low maintain cost.
Advantages:
1. The components in the area in contact with the product are food-safe
2. Advanced PLC Control , Easy operation and direct display;
3. Simple operation with SAFETY TOUCH and easy to clean
4. Adopted with Frequency Control: High speeds, Start stable, Low noise, Saving energy
5. Safety protect System，Burst detection with automatic machine stop
6. Widely used inmeat , food and non-food areas for the widest range of products.
Technical Parameters
|
Model |
GCF |
|
Speed (times/min) |
40-120 |
|
Voltage |
380V 50HZ |
|
Power (kW) |
3 |
|
Air pressure |
0.5—0.6 MPa |
|
Suit casing size |
Flat Width: 40 -135mm Cal: 25mm - 85mm |
|
Suit clips： |
The range of 15 and 18 |
|
The length of stretch |
36-100mm (optional) |
|
The height of sealing |
980—1050 mm |
|
External Dim. |
1200×900×1900mm |
|
Weight (kg) |
approx.560 |
